Used ULMER SF40 REINECKER  | CNC End profile grinding machine for sale

Technical Data:

  • Travels:
    • X-axis 450 mm
    • Z-axis 250 mm
  • Resolution:
    • X, Z-axis: 0.001 mm
    • C-axis: 0.001º
  • Rapid traverse X / Z: 15 / 30 m/min.
  • Grinding spindle:
    • Motor spindle ø x length: 140 x 300 mm
    • Drive power S6: 14 kW / 170 Hz
    • Infinitely variable speed: 1,000 to 7,500 min-1 / 250 Hz
    • Torque const.: 27 Nm to 5,000 min-1
    • Grinding wheel ø max.: 350 mm
    • Cutting speed: <140 m/s
  • Workpiece spindle (C-axis):
    • Mounting taper: SK50
    • Max. speed: 3,000 min-1
    • Torque max.: 28 Nm
  • Dimensions WxDxH: 1,900 x 1,900 x 1,900 mm
  • Accessories:
    • NUMROTO Plus control and softare Cylindrical grinding, loader, in-process measurement
    • Probe for in-process measurement, incl. probing cycles
    • 3D collision monitoring
    • Interpolating C-axis
    • Balancing system for grinding wheel in the machine
    • Automatic chain loader
    • Automatic bar feed
    • Coolant pressure increase
    • Oil pan
    • K&B fire extinguishing system incl. fire damper
    • Connections for central coolant supply and oil mist extraction
    • Collet chuck W20 UP
    • Schunk hydraulic chuck
  • General information:
    • The machine is functional, in very good condition and can be inspected by appointment.

The ULMER SF 40 REINECKER end facing machine stands for:

  • Production of points, chamfers, radii and their combination at the ends of cylindrical tools made of solid carbide, HSS and ceramic.
  • Grinding unit with a liquid-cooled motor spindle.
  • Variable spindle arrangement of the grinding unit for more flexibility, parallel or perpendicular.
  • Up to four different grinding wheels can be mounted on one holder.
  • Use of different chuck clamping systems.
  • Measuring probe for detecting the axial workpiece position and angular position of the cooling channels.
  • Automatic loading devices are available as an option.
  • NUM Flexium+ CNC control with powerful NUM DriveX drives and integrated NUM-Safe safety architecture.
